R-Series Datum Chuck System

• Pneumatic chuck mechanical self-locking clamping structure design, with pneumatic unlocking, automatic cleaning and air tightness detection function;

• Chuck repeatability <0.003mm, for high-precision manufacturing, heavy-duty cutting, clamping and quick-change standard interface;

• The chuck is pneumatically unlocked for easy disassembly and reassembly, and the sub-clamps can be realized in off-line clamping quick-change mode to increase the machine tool turnover rate;

• The standardized modular design of the chuck and fixture can be universally used in all kinds of flexible extension applications for industrial systems.

• Industry common standard interface, high versatility, can realize automated standard operation.




■　 Repeat positioning accuracy: ＜0.003mm

■　 Clamping force: 10000N

■　 Unlocking air pressure: 0.5Mpa-0.8Mpa

■　 Positioning reference surfaces are self-cleaning, airtightness checking and anti-debris cleaning of bores

■　 Fixed indexing position: 4x90°

■　 Clamping load: 45kg
